Specifications
Amp | 190 A |
Bottom Mounting Foot Width (B) | 14 mm |
Diameter (D.1) | 9 mm |
Diameter (D.2) | 9 mm |
Diameter (D.3) | M8x1.25 mm |
Diameter (D.4) | M8x1.25 mm |
Grooves | 7 qty |
Length (L.1) | 185 mm |
Mount Inside Length or Pad Mount C-C (C) | 61 mm |
OEM Product | No |
Outside Diameter (O.D.1) | 56.5 mm |
Plug Code | PL_2300 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley to Mount Distance (A) | 31 mm |
Pulley Type | SOLID |
Unit Type | HITACHI |
Voltage | 12 V |
Water Cooled | Yes |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
BENTLEY | Continental coupe 6.0 | [BEB] | 06.2003-12.2011 |
BENTLEY | Continental coupe 6.0 | [BWR] | 06.2003-12.2011 |
BENTLEY | Continental Flying Spur 6.0 | [BEB] | 03.2005-12.2010 |
BENTLEY | Continental Flying Spur 6.0 | [BWR] | 03.2005-12.2010 |
BENTLEY | Continental Flying Spur 6.0 | [BWRA] | 09.2008-12.2010 |
BENTLEY | Continental Flying Spur 6.0 FLEX | [BWRA] | 09.2008-02.2013 |
BENTLEY | Continental Flying Spur 6.0 FLEX | [CKHC] | 09.2008-02.2013 |
BENTLEY | Continental kabriolet 6.0 AWD | [BEB] | 06.2006-04.2011 |
BENTLEY | Continental kabriolet 6.0 AWD | [BWR] | 06.2006-04.2011 |
BENTLEY | Continental kabriolet 6.0 AWD | [CKHD] | 06.2006-04.2011 |
BENTLEY | Continental kabriolet 6.0 FLEX | [CKHA] | 03.2010-12.2013 |
Reference Information
07C903021J 555016RI 28-8550 ALT32344 LR1190-906E LR1190-906C LRA4441 UD20865A LR1190-906 LR1190-906B A2118S 305.419.190 LRA04441 AEG1279 ALH2428 ALT3177Video/Publications
07C903021J 28-8550 305.419.190 555016RI AEG1279 ALH2428 ALT32344 LR1190-906 LR1190-906B LR1190-906C LR1190-906E LRA04441 LRA4441 UD20865A A2118SAdd Your Number
