Specifications
Amp | 136 A |
Bottom Mounting Foot Width (B) | 14 mm |
Diameter (D.1) | 11 mm |
Diameter (D.2) | 11 mm |
Diameter (D.3) | M10x1.5 mm |
Diameter (D.4) | M10x1.5 mm |
Grooves | 8 qty |
Length (L.1) | 220 mm |
Mount Inside Length or Pad Mount C-C (C) | 66 mm |
OEM Product | No |
Outside Diameter (O.D.1) | 60 mm |
Plug Code | PL_2802 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley Type | SOLID |
Pulley to Mount Distance (A) | 46.5 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
DODGE | Ram 2500 5.9Di V6 | [ETC] | 01.2002-12.2005 |
DODGE | Ram 2500 5.9Di V6 4X4 | [ETC] | 01.2002-12.2005 |
Reference Information
ALT10592 ALB0018 K04801475AA 124525041 90-15-6434N LRA4221 ALTJ545 CAL10022AS LRA04221 2010022 0124525041 27-7830 PRAS461 56028732AA 90-15-6434 835.592.136 ALTS461 K56028732AA 20101220BN A-6429 ALT120220A UD90063A ALT1544 13987R 160-55140 EAA-222077 13987NVideo/Publications
0124525041 13987N 13987R 160-55140 2010022.0 20101220BN 27-7830 56028732AA 835.592.136 90-15-6434 90-15-6434N A-6429 ALB0018 ALT10592 ALT120220A ALTJ545 ALTS461 CAL10022AS EAA-222077 LRA04221 LRA4221 PRAS461 UD90063AAdd Your Number
