Associated Numbers
S9024 9142722 123708003Specifications
B+ Stud Diameter & Thread Pitch (B+) | M10x1.5 .mm |
Coil Bolt Diameter & Thread Pitch (Coil Bolt) | M8x1.25 mm |
Coil Bolt Length | 17 mm |
Inside Diameter (I.D.1) | 23.5 mm |
L.B+ | 26.5 mm |
Length (L.1) | 67 mm |
Outside Diameter (O.D.1) | 54.5 mm |
Outside Diameter (O.D.2) | 55 mm |
Type | Solenoid |
Unit Type | MAGNETON |
Voltage | 12 V |
Reference Information
UD41514SS 6660-6211 7154.612 SB-172 SB-163 SB-174 6660-6211-2 66-9100Video/Publications
S9024 UD41514SS S9054 SB-163 SB-174 123708003 6660-6211-2 66-9100 6660-6211 9142722 9142744 7154.612 SB-172Add Your Number
