Associated Numbers
AZJ3160 AZJ3199 AZJ3222 11130537 11130626 11130673 MS321 MS356 MS613Specifications
B+ Stud Diameter & Thread Pitch (B+) | M10x1.5 .mm |
Coil Bolt Diameter & Thread Pitch (Coil Bolt) | M10x1.5 mm |
Coil Bolt Length | 18.6 mm |
Inside Diameter (I.D.1) | 30 mm |
L.B+ | 23.8 mm |
Length (L.1) | 85.7 mm |
Outside Diameter (O.D.1) | 60.9 mm |
Outside Diameter (O.D.2) | 54 mm |
Type | Solenoid |
Unit Type | ISKRA / LETRIKA |
Voltage | 24 V |
Reference Information
72737659 MSX LET16.905.752 UD11957(LETRIKA)SS 366KIT 16.905.752 SOL79004 MSX366Video/Publications
11130626 72737659 AZJ3222 LET16.905.752 11130537 11130673 UD11957(LETRIKA)SS MS356 MS321 MS613 MSX AZJ3160 366KIT 16.905.752 AZJ3199 MSX366Add Your Number
