Associated Numbers
9142602 9142748 9142687 S9053 9142602 9142748 9142687 S9053Specifications
| B+ Stud Diameter & Thread Pitch (B+) | M10x1.5 .mm |
| Coil Bolt Diameter & Thread Pitch (Coil Bolt) | M8x1.25 mm |
| Coil Bolt Length | 18 mm |
| Inside Diameter (I.D.1) | 24 mm |
| L.B+ | 25.5 mm |
| Length (L.1) | 67.8 mm |
| Outside Diameter (O.D.1) | 54.5 mm |
| Outside Diameter (O.D.2) | 54.5 mm |
| Type | Solenoid |
| Unit Type | MAGNETON |
| Voltage | 12 V |
Reference Information
SS9025 SOLX092 7155882Video/Publications
9142748 S9053 SS9025 9142602 9142745 S9060 9142687 S9052 7155882Add Your Number
