Associated Numbers
S5173Specifications
| B+ Stud Diameter & Thread Pitch (B+) | M10x1.5 .mm |
| Coil Bolt Diameter & Thread Pitch (Coil Bolt) | M10x1.5 mm |
| Coil Bolt Length | 20 mm |
| Inside Diameter (I.D.1) | 29 mm |
| L.B+ | 31 mm |
| Length (L.1) | 107.5 mm |
| Outside Diameter (O.D.1) | 55.5 mm |
| Outside Diameter (O.D.2) | 54.5 mm |
| Type | Solenoid |
| Unit Type | MITSUBISHI |
| Voltage | 24 V |
Reference Information
UD42303SSVideo/Publications
S5173 S5442S UD42303SS S5028 M9T66771Add Your Number
