Associated Numbers
M1T68781 M001T68781Specifications
| B+ Stud Diameter & Thread Pitch (B+) | M8x1.25 .mm |
| Coil Bolt Diameter & Thread Pitch (Coil Bolt) | M8x1.25 mm |
| Coil Bolt Length | 14.4 mm |
| Inside Diameter (I.D.1) | 24.8 mm |
| L.B+ | 13.5 mm |
| Length (L.1) | 71.8 mm |
| Outside Diameter (O.D.1) | 51.6 mm |
| Outside Diameter (O.D.2) | 44.5 mm |
| Type | Solenoid |
| Unit Type | MITSUBISHI |
| Voltage | 12 V |
Reference Information
227346 UD00513SS 66-8371 SOL5029 M371XC4075 M371X95275Video/Publications
M001T68781 227346 UD00513SS M1T68781 66-8371 M371XC4075 M371X95275Add Your Number
