Associated Numbers
M1T84981ZCSpecifications
| B+ Stud Diameter & Thread Pitch (B+) | M8x1.25 mm |
| Coil Bolt Diameter & Thread Pitch (Coil Bolt) | M8x1.25 mm |
| Coil Bolt Length | 14.2 mm |
| Inside Diameter (I.D.1) | 25.2 mm |
| Inside Diameter (I.D.1) | 25.2 mm |
| L.B+ | 14.2 mm |
| Length (L.1) | 68.8 mm |
| Outside Diameter (O.D.1) | 51.5 mm |
| Outside Diameter (O.D.2) | 45.4 mm |
| Type | Solenoid |
| Unit Type | MITSUBISHI |
| Voltage | 12 V |
Reference Information
333785Video/Publications
M1T84981ZC 333785Add Your Number
