S4028Specifications
B+ Stud Diameter & Thread Pitch (B+) | M8x1.25 .mm |
Coil Bolt Diameter & Thread Pitch (Coil Bolt) | M8x1.25 mm |
Coil Bolt Length | 15 mm |
Inside Diameter (I.D.1) | 25.3 mm |
L.B+ | 25.2 mm |
Length (L.1) | 58.7 mm |
Outside Diameter (O.D.1) | 53.9 mm |
Outside Diameter (O.D.2) | 46.5 mm |
Type | Solenoid |
Unit Type | LUCAS/MARELLI |
Voltage | 12 V |
Reference Information
85541560010 9947959 SND1613 230809 ZM7595 85541260 85541010 85541560 66-9320 85541400 227742 1014312 SOL9015 138532 ZM3595 SSO30102 CQ2030759 CSO30102Video/Publications
085541560010 9947959 SND1613 230809 ZM7595 85541260 85541010 63102003 66-9320 85541400 227742 63223200 63101008 1014312 138532 ZM3595 S4015 S4028 SSO30102 CQ2030759 CSO30102Add Your Number
