Associated Numbers
D10E85 D10E92 D10E921 D10E922 D9E113 D9E114 D9E137 D9E138 D9E237 D9E238 D9E276 D9E39 D9E45 D9E76 D9E761 D9E77 D9E771 D9E772 D9E773 D9E774 D9E776 D9E95 D9R112 D9R237 D9RP256Specifications
| B+ Stud Diameter & Thread Pitch (B+) | M8x1.25 .mm |
| Coil Bolt Diameter & Thread Pitch (Coil Bolt) | M8x1.25 mm |
| Coil Bolt Length | 9.15 mm |
| Inside Diameter (I.D.1) | 25.3 mm |
| L.B+ | 14.5 mm |
| Length (L.1) | 60.8 mm |
| Outside Diameter (O.D.1) | 53.9 mm |
| Outside Diameter (O.D.2) | 44.4 mm |
| Type | Solenoid |
| Unit Type | VALEO |
| Voltage | 12 V |
Reference Information
133533 E7448 60-20-25001 106143 106142 ZM594 SSO15109 SOL0023 182460 227519 227987 594053 NE142 SND1296 CED546 UD805249(VALEO)SS CED537 CED548 1010932 CSO15109 E7450 NE141Video/Publications
E7448 106143 106142 SSO15109 D10E92 D9E77 227987 D9E761 D9E39 594053 SND1296 D9RP256 D9E95 CED546 UD805249(VALEO)SS D9E76 CED548 1010932 E7450 133533 60-20-25001 ZM594 D9R112 D9E114 D9E45 D9E774 D9E137 182460 D9E138 D9E237 D9E776 227519 D9E238 D9R237 D10E85 D9E276 D9E771 D9E772 D9E113 D9E773 NE142 CED537 CSO15109 NE141 D10E922 D10E921Add Your Number
