Specifications
| B+ Stud Diameter & Thread Pitch (B+) | M10x1.5 .mm |
| Coil Bolt Diameter & Thread Pitch (Coil Bolt) | M8x1.25 mm |
| Coil Bolt Length | 12.6 mm |
| L.B+ | 24.1 mm |
| Length (L.1) | 108.1 mm |
| Outside Diameter (O.D.1) | 57 mm |
| Outside Diameter (O.D.2) | 56.8 mm |
| Type | Solenoid |
| Unit Type | DELCO |
| Voltage | 24 V |
Reference Information
SOL2055 UD805189(DELCO)SS 10524712Video/Publications
10524712 UD805189(DELCO)SSAdd Your Number
