Associated Numbers
0001368088Specifications
B+ Stud Diameter & Thread Pitch (B+) | M10x1.5 .mm |
Coil Bolt Diameter & Thread Pitch (Coil Bolt) | M10x1.5 mm |
Coil Bolt Length | 14 mm |
Inside Diameter (I.D.1) | 30 mm |
L.B+ | 19.6 mm |
Length (L.1) | 82.4 mm |
Outside Diameter (O.D.1) | 61.5 mm |
Outside Diameter (O.D.2) | 56 mm |
Type | Solenoid |
Unit Type | BOSCH |
Voltage | 24 V |
Reference Information
699076 331402211 1319443 BOS0331402211 UD802494(BOSCH)SSVideo/Publications
0331402211 0001368088 1368088 01319443 699076 BOS0331402211 UD802494(BOSCH)SSAdd Your Number
