Associated Numbers
S0568 0001106405 0001106406 S0568 0001106405 0001106406
12-41-7-540-897 BMW, Starter, 12V, CW, PMGR, 0.9kW
Enlarge 0001106405 0001106405 Bosch, Starter, 12V, 10T, CW, PMGR, 0.9kW, New
0001106406 Bosch, Starter, 12V, CW, PMGR, 0.9kW
5802AR Peugeot, Starter, 12V, CW, PMGR, 0.9kW
V7540897 Peugeot, Starter, 12V, CW, PMGR, 0.9kW
V7552105 Peugeot, Starter, 12V, CW, PMGR, 0.9kW
13417561559 Bosch 2339305050 Cargo 330224 KRAUF SSB3224AB 0001106405, 0001106406, 12417582308,
Specifications
Product features :
| Starter solenoids | |
| Voltage [ V ] | 12 |
| I.D.1 [ mm ] | 24.00 |
| O.D.1 [ mm ] | 52.60 |
| O.D.2 [ mm ] | 45.30 |
| L.1 [ mm ] | 63.00 |
| B+ [ mm ] | M8x1.25 |
| L.B+ [ mm ] | 20.50 |
| Coil bolt [ mm ] | M8x1.25 |
| L.Coil bolt [ mm ] | 14.50 |
| B+ Stud Diameter & Thread Pitch (B+) | M8x1.25 .mm |
| Coil Bolt Diameter & Thread Pitch (Coil Bolt) | M8x1.25 mm |
| Coil Bolt Length | 14.5 mm |
| Inside Diameter (I.D.1) | 24 mm |
| L.B+ | 20.5 mm |
| Length (L.1) | 63 mm |
| Outside Diameter (O.D.1) | 52.6 mm |
| Outside Diameter (O.D.2) | 45.3 mm |
| Type | Solenoid |
| Unit Type | BOSCH |
| Voltage | 12 V |
Reference Information
SSB3224 SOL1253 2339305050 330224 UD45981SS 13627566052 13417561559Video/Publications
S0568 SSB3224 2339305050 330224 1106406 UD45981SS 0001106406 13627566052 0001106405 13417561559 1106405Add Your Number
