Associated Numbers
0001115045 0001115041 0001115040 0001115046 0001115076Specifications
B+ Stud Diameter & Thread Pitch (B+) | M8x1.25 .mm |
Coil Bolt Diameter & Thread Pitch (Coil Bolt) | M8x1.25 mm |
Coil Bolt Length | 8.5 mm |
Inside Diameter (I.D.1) | 26.1 mm |
L.B+ | 16.5 mm |
Length (L.1) | 71.4 mm |
Outside Diameter (O.D.1) | 52.3 mm |
Outside Diameter (O.D.2) | 46 mm |
Type | Solenoid |
Unit Type | BOSCH |
Voltage | 12 V |
Reference Information
1014600 UD802580(BOSCH)SS 2339305142 239841 12417798034 81014600 BOS2339305045 2339305045Video/Publications
UD802580(BOSCH)SS 2339305142 239841 1014600 0001115045 1115076 0001115046 1115040 1115041 0001115040 1115046 0001115041 0001115076 1115045 12417798034 81014600 BOS2339305045 2339305045Add Your Number
