Associated Numbers
0001138009 0001139013 0001138009 0001139013Specifications
| B+ Stud Diameter & Thread Pitch (B+) | M8x1.25 .mm |
| Coil Bolt Diameter & Thread Pitch (Coil Bolt) | M8x1.25 mm |
| Coil Bolt Length | 13.7 mm |
| Inside Diameter (I.D.1) | 24.3 mm |
| L.B+ | 20.4 mm |
| Length (L.1) | 64.2 mm |
| Outside Diameter (O.D.1) | 52.5 mm |
| Outside Diameter (O.D.2) | 45.3 mm |
| Type | Solenoid |
| Unit Type | BOSCH |
| Voltage | 12 V |
Reference Information
335056 77365345 SOL1158 2339305124Video/Publications
S0314 335056 77365345 0001138030 1138009 1139013 0001139013 0001138009 2339305124 1138030Add Your Number
