Associated Numbers
0001371020 1371020Specifications
| B+ Stud Diameter & Thread Pitch (B+) | M12x1.75 .mm |
| Coil Bolt Diameter & Thread Pitch (Coil Bolt) | M12x1.75 mm |
| Coil Bolt Length | 24.2 mm |
| Inside Diameter (I.D.1) | 32 mm |
| L.B+ | 35.4 mm |
| Length (L.1) | 98.4 mm |
| Outside Diameter (O.D.1) | 66.3 mm |
| Outside Diameter (O.D.2) | 56.6 mm |
| Type | Solenoid |
| Unit Type | BOSCH |
| Voltage | 24 V |
Reference Information
SOL1150 2339403018 SND11062 BOS2339403018Video/Publications
1371020 2339403018 SND11062 0001371020 BOS2339403018Add Your Number
