Associated Numbers
0001231013 0001231041 0001368313Specifications
| B+ Stud Diameter & Thread Pitch (B+) | M10x1.5 .mm |
| Coil Bolt Diameter & Thread Pitch (Coil Bolt) | M10x1.5 mm |
| Coil Bolt Length | 20.5 mm |
| Inside Diameter (I.D.1) | 29.8 mm |
| L.B+ | 34.5 mm |
| Length (L.1) | 82.9 mm |
| Outside Diameter (O.D.1) | 61.7 mm |
| Outside Diameter (O.D.2) | 53.8 mm |
| Type | Solenoid |
| Unit Type | BOSCH |
| Voltage | 24 V |
Reference Information
2339402165 233629 2339402124 233583 SND11044 CQ2030040 SOL1379Video/Publications
2339402165 233629 0001231041 2339402124 233583 1231041 0001231013 1231013 1368313 SND11044 CQ2030040 0001368313Add Your Number
