Associated Numbers
0001230001 1230001Specifications
| B+ Stud Diameter & Thread Pitch (B+) | M10x1.5 .mm |
| Coil Bolt Diameter & Thread Pitch (Coil Bolt) | M10x1.5 mm |
| Coil Bolt Length | 20 mm |
| Inside Diameter (I.D.1) | 30 mm |
| L.B+ | 35 mm |
| Length (L.1) | 82.5 mm |
| Outside Diameter (O.D.1) | 61.5 mm |
| Outside Diameter (O.D.2) | 53.5 mm |
| Type | Solenoid |
| Unit Type | BOSCH |
| Voltage | 12 V |
Reference Information
11521510 SOL1146 2339402119Video/Publications
0001230001 1230001 2339402119 0011521510Add Your Number
