Associated Numbers
AZF4220 AZF4229 AZF4286 AZF4329 11130728 11130841 11130842 11131829 11131862 11132066 11132194 MS141 MS446 MS232 MS429 MS67 MS199Specifications
Inside Diameter (I.D.1) | 14.3 mm |
Length (L.1) | 82 mm |
Length (L.2) | 20 mm |
No./Splines | 10 qty |
No./Teeth | 9 qty |
Outside Diameter (O.D.1) | 62 mm |
Outside Diameter (O.D.2) | 34.2 mm |
Rotation | CW |
Type | Drive |
Unit Type | ISKRA / LETRIKA |
Reference Information
DRV7912 72738614 54-9509 335625 16.904.625 060.000.842.310 01-045 SDI4625 UD11934(LETRIKA)SD MSX724 61-23-14016 MAHMSX724 SDV38335 1979 LET16.904.625Video/Publications
MS67 72738614 MS232 MS199 AZF4507 11131862 AZF4229 AZF4329 AZF4220 AZF4286 UD11934(LETRIKA)SD MSX724 61-23-14016 11131829 LET16.904.625 11130728 11130842 S9099 54-9509 11130841 MS141 16.904.625 AZF4514 11132066 AZF4515 11132194 MS446 MSX MS429 724Add Your Number
