Associated Numbers
M1T85682 M001T85682 M1T85682 M001T85682Specifications
| Inside Diameter (I.D.1) | 12 mm |
| Length (L.1) | 51 mm |
| Length (L.2) | 16.5 mm |
| No./Splines | 8 qty |
| No./Teeth | 12 qty |
| Outside Diameter (O.D.1) | 45 mm |
| Outside Diameter (O.D.2) | 32.4 mm |
| Rotation | CW |
| Type | Drive |
| Unit Type | MITSUBISHI |
Reference Information
UD00453SD DRV5054Video/Publications
M1T85682 UD00453SD M001T85682 S5113Add Your Number
