Associated Numbers
63221504 63221534 63221504 63221534Specifications
Inside Diameter (I.D.1) | 11.6 mm |
Length (L.1) | 70.8 mm |
Length (L.2) | 17.6 mm |
No./Splines | 12 qty |
No./Teeth | 9 qty |
Outside Diameter (O.D.1) | 45 mm |
Outside Diameter (O.D.2) | 25.8 mm |
Rotation | ACW |
Type | Drive |
Unit Type | LUCAS/MARELLI |
Reference Information
74892751 1620 9917925 132302 1017355 9959566 SDV37029 00-040 UD11641SD 79033957 85540541Video/Publications
63221504 63221534 9917925 132302 1017355 85540541 74892751 1620 9959566 SDV37029 00-040 UD11641SD 79033957Add Your Number
