Associated Numbers
63223103 63223104 63230001 63230003 63293103 63293104 NAD100740 NAD101070 NAD101080 63223103 63223104 63230001 63230003 63293103 63293104 NAD100740 NAD101070 NAD101080Specifications
Inside Diameter (I.D.1) | 12 mm |
Length (L.1) | 84.6 mm |
Length (L.2) | 39 mm |
No./Splines | 12 qty |
No./Teeth | 9 qty |
Outside Diameter (O.D.1) | 25.2 mm |
Outside Diameter (O.D.2) | 44.8 mm |
Rotation | ACW |
Type | Drive |
Unit Type | LUCAS/MARELLI |
Reference Information
ZN1496 81015839 AMB0463 SDE8865 138865 00-018 1.01.1496.0 85541100 CQ2010080 18919 225640 1496 SDV38153 1015839 085541100010Video/Publications
ZN1496 63220104 81015839 AMB0463 SDE8865 138865 00-018 1.01.1496.0 63233103 63230001 63293104 CQ2010080 63293103 63230003 63223103 63233104 18919 225640 63223104 SDV38153 1015839 085541100010Add Your Number
