Associated Numbers
63223039 63293039 S4016 63223039 63293039 S4016Specifications
Height (H.1) | 97.4 mm |
Inside Diameter (I.D.1) | 10.5 mm |
Mount Hole Center - Center (O.1) | 74.2 mm |
Mount Hole Center - Center (O.2) | 74.2 mm |
Mount Hole Center - Center (O.3) | 105 mm |
No./Mount holes | 4 qty |
No./Mount holes with thread | 2 qty |
Spigot Diameter (A) | 82.5 mm |
Type | Drive End |
Unit Type | LUCAS/MARELLI |
Reference Information
BKT40996 BDES9012 83225739 138561Video/Publications
BKT40996 63223039 83225739 138561 63293039 S4016Add Your Number
