Associated Numbers
0001410037 0001415008 0001417042 0001417043 9000084012 0001410037 0001415008 0001417042 0001417043 9000084012Specifications
Height (H.1) | 81 mm |
Inside Diameter (I.D.1) | 34 mm |
Mount Hole Center - Center (O.1) | 127 mm |
Mount Hole Center - Center (O.2) | 127 mm |
Mount Hole Center - Center (O.3) | 127 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
Spigot Diameter (A) | 92 mm |
Type | Drive End |
Unit Type | BOSCH |
Reference Information
2005825099 BKT40189 UD03475SBR 132220 BOS2005825099 ZN2618 BDES1300 SBB2220 192954 11991472 19024355 1011932 2618 6527-151 1.03.0618.0Video/Publications
2005825099 1410037 1415008 0001410037 0001415008 9000084012 9000084013 192954 11991472 19024355 S0010 6527-151 1417042 1417043 BKT40189 UD03475SBR 132220 BOS2005825099 ZN2618 SBB2220 0001417042 0001417043 1011932 2618 1.03.0618.0Add Your Number
