Associated Numbers
28100-18700 UD17070S 0350-552-0512 28100-1820 28100-1820A 28100-1820B 28100-1820C 28100-1820D 28100-1820E 28100-1820F 28100-1821A 28100-1821B 28100-1821NE 28100-2062 28100-2063 28100-2064 28100-2150 28100-2270 28100-2271 OK850-18-400 OK851-18-400B STW4341 STW8341 0350-502-0010 0350-502-0011 0350-502-0012 0350-502-0013 0350-502-0014 0350-502-0015 0350-502-0016 0350-502-0017 0350-502-0018 0350-502-0019 0350-502-0041 0350-522-0310 0350-552-0330 0350-552-0332 0350-552-0513 0350-552-0514 0350-552-0515 0350-552-0516 0350-552-0517 0350-602-0130 0350-602-0131 0350-602-0132 0350-602-0133 0350-602-0134 0350-602-0135 0350-602-0136 0350-602-0137 0350-602-0138 0350-602-0139 0350-602-0150 0351-602-1032Specifications
Kilowatt | 5.5 kW |
Length (L.1) | 347 mm |
Mount Hole Center - Center (O.1) | 140 mm |
Mount Hole Center - Center (O.2) | 118.5 mm |
Mount Hole Center - Center (O.3) | 106.5 mm |
Mount Hole Diameter (C.1) | 13.5 mm |
Mount Hole Diameter (C.2) | 13.5 mm |
Mount Hole Diameter (C.3) | 13.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
Pinion at Rest (B) | 27 mm |
Rotation | CW |
Spigot Diameter (A) | 100 mm |
Unit Type | SAWAFUJI |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
HINO | Engine | [DM100] | |
HINO | Engine | [DQ100] | |
HINO | Engine | [EC100] | |
HINO | Engine | [EH100] | |
HINO | Engine | [EH300] | |
HINO | Engine | [EH700] | |
HINO | Engine | [H06C] | |
HINO | Engine | [H06CT] | |
HINO | Engine | [H07] | |
HINO | Engine | [H07CT] | |
HINO | Engine | [H07CT(A)] | |
HINO | Engine | [H07D] | |
HINO | Engine | [H08C] |
Reference Information
0350-602-0136 0350-602-0137 28100-18700 0350-602-0138 0350-602-0139 0350-602-0150 OK851-18-400B 0350-602-0130 0350-602-0131 0350-602-0132 STW4341 0350-602-0133 0350-602-0134 0350-602-0135 28100-2064 0350-552-0516 28100-2063 0350-552-0517 0351-602-1032 28100-2062 0350-552-0514 0350-552-0515 0350-552-0512 0350-552-0513 0350-522-0310 CGB-23059 OK850-18-400 0350-502-0041 STW8341 28100-2150 28100-2271 28100-2270 UD17070SVideo/Publications
0350-502-0041 0350-522-0310 0350-552-0512 0350-552-0513 0350-552-0514 0350-552-0515 0350-552-0516 0350-552-0517 0350-602-0130 0350-602-0131 0350-602-0132 0350-602-0133 0350-602-0134 0350-602-0135 0350-602-0136 0350-602-0137 0350-602-0138 0350-602-0139 0350-602-0150 0351-602-1032 28100-18700 28100-2062 28100-2063 28100-2064 28100-2150 28100-2270 28100-2271 CGB-23059 OK850-18-400 OK851-18-400B STW4341 STW8341 UD17070SAdd Your Number
