Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
FORD
Price:
NZ$ 245.28 including GST
NZ$ 213.29 excluding GST
or four payments of $61.32
with
Learn More
each
S9376S
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Associated Numbers
25-3260 F89Z11002BA UD16856S DRS0594 DS1704 S-2082 5L2T-11000-AA F77U-11000-AA F89U-11000-BA F89U-11000-BB F89Z-11002-BA STF2597 LRS01707 880.530.103 3273N 3273R 91-02-5877 91-02-5877N STR82437Specifications
| Kilowatt | 1.40 kW |
| Length (L.1) | 226 mm |
| Mount Hole Center - Center (O.1) | 132 mm |
| Mount Hole Diameter (C.1) | 11 mm |
| Mount Hole Diameter (C.2) | 11 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 10 qty |
| OEM Product | No |
| Pinion at Rest (B) | 16 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 76 mm |
| Unit Type | FORD |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| FORD | Aerostar 4.0 i V6 4WD | 09.1989-12.1997 | |
| FORD | Explorer 4.0 V6 4WD | 10.1996-12.2001 | |
| FORD | Explorer 4.0 V6 4WD | 10.1998-12.2001 |
Reference Information
| 25-3260 | ELSTOCK |
| 3273N | WAI / TRANSPO |
| 3273R | WAI / TRANSPO |
| 5L2T-11000-AA | FORD |
| 880.530.103 | PSH |
| 91-02-5877 | WILSON |
| 91-02-5877N | WILSON |
| ANM12814X | ANDEL |
| DRS0594 | DELCO |
| DS1704 | DELCO |
| F77U-11000-AA | FORD |
| F89U-11000-BA | FORD |
| F89U-11000-BB | FORD |
| F89Z-11002-BA | FORD |
| LRS01707 | LUCAS |
| LRS1707 | LUCAS |
| S135.831 | PSH |
| S-2082 | DIXIE |
| S9376S | AS-PL |
| SA1000RM | FORD |
| SA-860 | FORD |
| STF2597 | KRAUF |
| STR82437 | WOODAUTO |
| UD16856S | AS-PL |
| UD20616S | AS-PL |
Video/Publications
