Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
ISKRA / LETRIKA
Price:
NZ$ 521.24 including GST
NZ$ 453.25 excluding GST
or four payments of $130.31
with
Learn More
each
S9365S
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
AZF4593Associated Numbers
11.132.303 AZF4593 UD16546S CST21612GS 011912354 01912354 TS-6263 273-42205 45-4030 IS1117 11.132.302 AZF4360 11.131.266 11.131.357 AZF4575 RE522334 RE536008 SE502733 STI4593 LRS02358 MS165 72735793 88214719 S5012L 20419216OE 6021612.1Specifications
| Insulated Earth | Yes |
| Kilowatt | 4 kW |
| Length (L.1) | 341 mm |
| Mount Hole Center - Center (O.1) | 127 mm |
| Mount Hole Center - Center (O.2) | 90 mm |
| Mount Hole Center - Center (O.3) | 90 mm |
| Mount Hole Diameter (C.1) | 11 mm |
| Mount Hole Diameter (C.2) | 11 mm |
| Mount Hole Diameter (C.3) | 11 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 10 qty |
| OEM Product | No |
| Pinion at Rest (B) | 47 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 89 mm |
| Unit Type | ISKRA / LETRIKA |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CUMMINS | Engine 5.9 | 01.1995-01.2004 | |
| CUMMINS | M75 | [4045TF] | |
| JOHN DEERE | Engine 4.5 | [4045AFM85] | |
| JOHN DEERE | Engine 4.5 | [4045DFM50] | |
| JOHN DEERE | Engine 4.5 | [4045DFM70] | 01.2004-01.2007 |
| JOHN DEERE | Engine 4.5 | [4045DFM70] | |
| JOHN DEERE | Engine 4.5 | [4045TFM50] | 01.2004-01.2007 |
| JOHN DEERE | Engine 4.5 | [4045TFM75] | |
| JOHN DEERE | Engine 4.5 | [4045TFM76] | |
| JOHN DEERE | Engine 4.5 | [4045TFM85] | |
| JOHN DEERE | Engine 6.8 | [6068AFM85] | |
| JOHN DEERE | Engine 6.8 | [6068FM75] | |
| JOHN DEERE | Engine 6.8 | [6068HFG55] | |
| JOHN DEERE | Engine 6.8 | [6068SFM50] | |
| JOHN DEERE | Engine 6.8 | [6068SFM75] | 01.2004-07.2011 |
| JOHN DEERE | Engine 6.8 | [6068TFM50] | |
| JOHN DEERE | Engine 6.8 | [6068TFM75] | |
| JOHN DEERE | Engine 6.8 | [6068TFM76] | |
| JOHN DEERE | Engine 9.0 | [6090AFM75] | |
| JOHN DEERE | Engine 9.0 | [6090AFM85] | |
| JOHN DEERE | Engine 9.0 | [6090SFM75] | |
| JOHN DEERE | Engine 9.0 | [6090SFM85] | |
| JOHN DEERE | PSS 6.8 | [6068HFC09] | |
| JOHN DEERE | PSS 6.8 | [6068HFG09] | |
| JOHN DEERE | PSX 6.8 | [6068HFC95] | |
| JOHN DEERE | PSX 6.8 | [6068HFG95] | |
| JOHN DEERE | PVS 6.8 | [6068HFC08] | |
| JOHN DEERE | PVS 6.8 | [6068HFG08] | |
| JOHN DEERE | PVX 6.8 | [6068HFC93] | |
| JOHN DEERE | PVX 6.8 | [6068HFC94] | |
| JOHN DEERE | PVX 6.8 | [6068HFG94] |
Reference Information
| 011912354 | CUMMINS |
| 01912354 | CUMMINS |
| 11.131.266 | ISKRA / LETRIKA |
| 11.131.357 | ISKRA / LETRIKA |
| 11.132.302 | ISKRA / LETRIKA |
| 11.132.303 | ISKRA / LETRIKA |
| 20419216OE | REAL |
| 273-42205 | DIXIE |
| 45-4030 | ELSTOCK |
| 6021612.1 | SANDO |
| 72735793 | MAHLE |
| 88214719 | POWERMAX |
| AZF4360 | ISKRA / LETRIKA |
| AZF4575 | ISKRA / LETRIKA |
| AZF4593 | ISKRA / LETRIKA |
| CST21612GS | CASCO |
| IS1117 | ISKRA / LETRIKA |
| LRS02358 | LUCAS |
| LRS2358 | LUCAS |
| MS165 | MAHLE |
| MS 165 | MAHLE |
| MS 627 | MAHLE |
| RE522334 | JOHN DEERE |
| S5012L | PRESTOLITE |
| SE502733 | JOHN DEERE |
| STI4593 | KRAUF |
| STR79162 | ELECTROLOG |
| STR7967 | ELECTROLOG |
| STRF326 | 3EFFE |
| TS-6263 | DIXIE |
| UD16546S | AS-PL |
Video/Publications
