Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
ISKRA / LETRIKA
Price:
NZ$ 509.29 including GST
NZ$ 442.86 excluding GST
or four payments of $127.32
with
Learn More
each
S9355S
No stock in NZ
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Associated Numbers
11.132.369 182-30501 273-42202 4470977 4510011 5904518 AZF4373 T434131 TS-6272 UD16543SSpecifications
| Kilowatt | 4.5 kW |
| Length (L.1) | 348 mm |
| Mount Hole Center - Center (O.1) | 90 mm |
| Mount Hole Center - Center (O.2) | 127 mm |
| Mount Hole Center - Center (O.3) | 90 mm |
| Mount Hole Diameter (C.1) | 11 mm |
| Mount Hole Diameter (C.2) | 11 mm |
| Mount Hole Diameter (C.3) | 11 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 10 qty |
| OEM Product | No |
| Pinion at Rest (B) | 28 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 89 mm |
| Unit Type | ISKRA / LETRIKA |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CATERPILLAR | CP56B 4.4 | [157HP] | |
| CATERPILLAR | CPS56B 4.4 | [157HP] | |
| CATERPILLAR | CS56B 4.4 | [157HP] | |
| CATERPILLAR | Engines 4.4 | [61-130HP] |
Reference Information
T434131 TS-6272 STR79382 11.132.369 CST21650GS UD16543S 701.010.103.090 273-42202 4510011 IS1407 AZF4373 20419056OE 182-30501 6021650.1 MS715 MAV236500 T400418 4470977 5904518Video/Publications
