Associated Numbers
245-25201 255461P 5263841 5268413 5319202 641.541.103 M81R3001 PREM81R3001 STP0063 STP9063 STR0063 UD15503SSpecifications
Kilowatt | 4.5 kW |
Length (L.1) | 315 mm |
Mount Hole Center - Center (O.1) | 89.5 mm |
Mount Hole Center - Center (O.2) | 89.5 mm |
Mount Hole Center - Center (O.3) | 126.5 mm |
Mount Hole Diameter (C.1) | 10.5 mm |
Mount Hole Diameter (C.2) | 10.5 mm |
Mount Hole Diameter (C.3) | 10.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 10 qty |
Pinion at Rest (B) | 46 mm |
Rotation | CW |
Spigot Diameter (A) | 89 mm |
Unit Type | CUMMINS |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CUMMINS | Engine 2.8 | [ISF] | |
CUMMINS | Engine 3.8 | [ISF] |
Reference Information
UD15503S STR9778 PREM81R3001 5319202 5263841 STP0063 S9340S 5268413 255461P STR0063 STRJ422 M81R3001 641.541.103 STP9063 245-25201Video/Publications
S9340S 245-25201 255461P 5263841 5268413 5319202 641.541.103 M81R3001 PREM81R3001 STP0063 STP9063 STR0063 STRJ422 UD15503SAdd Your Number
