Associated Numbers
06312-PAA-507RM 113398 17729N 17729R 2903726060 31200-P0A-004 31200-P0A-004RM 31200-P0A-A04 31200-PAA-A02 31200-PAA-A02RM 5862026060 5862061680 91-26-2037 91-26-2037N PAA0W PCB0X SM422-02 SM442-02 SM442-03 STR75610 STU3398 UD03382S
mxs805 702834 snj135 sm44204 31200-PCA-901 16-306
sm42228 16947
Specifications
| Kilowatt | 1.6 kW |
| Length (L.1) | 202 mm |
| Mount Hole Center - Center (O.1) | 119 mm |
| Mount Hole Diameter (C.1) | 11.5 mm |
| Mount Hole Diameter (C.2) | 11.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| Pinion at Rest (B) | 34 mm |
| Rotation | CW |
| Spigot Diameter (A) | 75 mm |
| Unit Type | MITSUBA |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| HONDA | Shuttle 2.3 16V | [F23A7] | 10.1997-06.2004 |
Reference Information
SM422-02 S9329S 17729R 2903726060 17729N PCB0X STU3398 PAA0W J5214038 31200-PAA-A02 91-26-2037N 31200-P0A-A04 STR75610 5862061680 91-26-2037 UD03382S 31200-P0A-004RM SM442-02 SM442-03 06312-PAA-507RM 5862026060 31200-P0A-004 STR5982 113398 31200-PAA-A02RMVideo/Publications
06312-PAA-507RM 113398 17729N 17729R 2903726060 31200-P0A-004 31200-P0A-004RM 31200-P0A-A04 31200-PAA-A02 31200-PAA-A02RM 5862026060 5862061680 91-26-2037 91-26-2037N J5214038 PAA0W PCB0X SM422-02 SM442-02 SM442-03 STR75610 STU3398 UD03382S S9329SAdd Your Number
