Associated Numbers
11.132.014 11.132.239 1201866 182-30498 451869 6021619 641.524.173 AZG4829 CST21619 CST21619AS CST21619ES CST21619GS CST21619OS CST21619RS IS1198 MS144 UD13094S(LETRIKA)Specifications
Kilowatt | 6.5 kW |
Length (L.1) | 378 mm |
Mount Hole Center - Center (O.1) | 127 mm |
Mount Hole Center - Center (O.2) | 127 mm |
Mount Hole Center - Center (O.3) | 127 mm |
Mount Hole Diameter (C.1) | 17 mm |
Mount Hole Diameter (C.2) | 17 mm |
Mount Hole Diameter (C.3) | 17 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 17 qty |
Pinion at Rest (B) | 48 mm |
Rotation | CW |
Spigot Diameter (A) | 124 mm |
Unit Type | ISKRA / LETRIKA |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
JENBACHER | Various Models |
Reference Information
11.132.239 MS MS144 1201866 STR7875 11.132.014 CST21619RS CST21619OS 144 AZG4829 IS1198 6021619 451869 182-30498 CST21619GS CST21619 CST21619ES UD13094S(LETRIKA) 641.524.173 CST21619ASVideo/Publications
11.132.014 11.132.239 1201866 182-30498 451869 6021619 641.524.173 AZG4829 CST21619 CST21619AS CST21619ES CST21619GS CST21619OS CST21619RS IS1198 MS 144 MS144 UD13094S(LETRIKA)Add Your Number
