Associated Numbers
SM442-38 UD13986SSpecifications
Kilowatt | 1.6 kW |
Length (L.1) | 257 mm |
Mount Hole Center - Center (O.1) | 123 mm |
Mount Hole Diameter (C.1) | 13 mm |
Mount Hole Diameter (C.2) | 13 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 60 mm |
Rotation | ACW |
Spigot Diameter (A) | 70 mm |
Unit Type | MITSUBA |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
ACURA | TL 3.0 V6 | 01.2004-12.2006 | |
HONDA | Accord 3.0 V6 | 01.2003-12.2007 |
Reference Information
17899N STU4243 SM442-43 S9313S 06312-RCA-516 SM442-38 31200-RCA-A02 31200-RCA-A01 UD13986S 06312-RCA-516RMVideo/Publications
SM442-38 UD13986S S9313SAdd Your Number
