Associated Numbers
361.504.103 4934622 4983068 M93R3014SE PREM93R3014SE STP3622 UD14326S 70-0801 361504103 PSH Cummins 662808 Dennis C4934622 C4983068 Prestolite M93R3014SESEL +line 10001100158 Weichai 1610036000026 5266537 show C5286774 M93R3014AM Wood Auto RNLM93R3014SE RNL STR81086 WOOSTR81086Specifications
Kilowatt | 6 kW |
Length (L.1) | 313 mm |
Mount Hole Center - Center (O.1) | 90 mm |
Mount Hole Center - Center (O.2) | 90 mm |
Mount Hole Center - Center (O.3) | 127 mm |
Mount Hole Diameter (C.1) | 11 mm |
Mount Hole Diameter (C.2) | 11 mm |
Mount Hole Diameter (C.3) | 11 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 10 qty |
Pinion at Rest (B) | 47 mm |
Rotation | CW |
Spigot Diameter (A) | 89 mm |
Unit Type | PRESTOLITE |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CUMMINS | Engine | ||
GOLDEN DRAGON | Various Models | ||
HIGER | 6119 | ||
HIGER | 6840 | ||
HIGER | 6885 | ||
HIGER | 6891 | ||
HIGER | KLQ6109Q | [ISDE270-30] | |
HIGER | KLQ6856E3 | [ISDE185-30] | |
HIGER | KLQ6896E3 | [ISDE210-30] | |
HIGER | KLQ6896QE3 | [IDE210-30S] | |
KAMAZ | 4308 | ||
KAMAZ | 5308 | ||
KING LONG | XMQ6900 | ||
YUTONG | Various Models | [ZK6737D] |
Reference Information
4983068 STP3622 361.504.103.150 M93R3014SE 256351P PREM93R3014SE C5286774 1.61004E+12 5266537 361.504.103.158 C4934622 UD14326S 4934622Video/Publications
361.504.103 4934622 4983068 M93R3014SE PREM93R3014SE STP3622 UD14326SAdd Your Number
