Associated Numbers
0-24000-3032 131.506.112 1811003070 1811003230 1811003231 185-24003 UD13956SSpecifications
Kilowatt | 4.5 kW |
Length (L.1) | 290 mm |
Mount Hole Center - Center (O.1) | 150 mm |
Mount Hole Diameter (C.1) | 15.5 mm |
Mount Hole Diameter (C.2) | 15.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
Pinion at Rest (B) | 43 mm |
Rotation | CW |
Spigot Diameter (A) | 105 mm |
Unit Type | NIKKO |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
ISUZU | FRR 32 | ||
ISUZU | FRR 33 | ||
ISUZU | FRR 500 | [6H1] | |
ISUZU | FRR 500 | [6HE1] | |
ISUZU | FRR 500 | [6HH1] | |
ISUZU | FSR 700 | ||
ISUZU | FTR | [6H1] | |
ISUZU | FTR | [6HE1] | |
ISUZU | FTR | [6HH1] | |
ISUZU | FTR 800 |
Reference Information
1811003231 1811003230 0-24000-3032 131.506.112 UD13956S 185-24003 1811003070 STR8826Video/Publications
0-24000-3032 131.506.112 1811003070 1811003230 1811003231 185-24003 UD13956SAdd Your Number
