S9302S - Brand new AS-PL Starter motor

Associated Numbers

11.131.315 11.131.535 11.131.975 11.131.984 11.131.990 114107 182-30102 234987A1 273-32103 3542185M93 3667037M91 6021144 760.002.103 8719R 9162904 AZE4125 AZE4212 AZE4214 AZE4216 AZE4579 CST21144 CST21144AS CST21144ES CST21144GS CST21144OS CST21144RS EAA-122194 IS1098 MAHMS4 MS4 SG9064 TS-6276 UD13624S AGCO 1482841M92 191068M94 4270745M2 ARROWHEAD SIA0019 CASEIH DEUTZ J&N ELECTRICAL PRODUCTS 410-29062 LANDINI LESTER 32561 LETRIKA/ISKRA 11131315 IS 1098 MAHLE 11131112 11131216 11131424 11131535 11131975 11131984 AZE4536 AZE4565 AZE4595 MS282 MASSEY FERGUSON MCCORMICK 706022A1 OTHER OEMS PERKINS 1447834M91 70-5600 lxs9302 MS399 11130904 Mahle show 11131990 11132170 Perkins Agco 35259300 Prestolite 35259310 Landini 36213 Sparex 4TNV9876011 Yanmar 4TNV98776011 72735632 760002103 PSH 8470 CEVAM 9000083000 Bosch 9000083072 9000453016 AZF4131 AZF4319 AZF4520 IS1053 IS1084 IS1184 LRS01624 Lucas

Specifications

Kilowatt	3.2 kW
Length (L.1)	277 mm
Mount Hole Center - Center (O.1)	127 mm
Mount Hole Center - Center (O.2)	90 mm
Mount Hole Center - Center (O.3)	90 mm
Mount Hole Diameter (C.1)	11 mm
Mount Hole Diameter (C.2)	11 mm
Mount Hole Diameter (C.3)	11 mm
No./Mount holes	3 qty
No./Mount holes with thread	0 qty
No./Teeth	10 qty
OEM Product	No
Pinion at Rest (B)	29.5 mm
Product Line	Standard Line
Product Type	Brand new
Rotation	CW
Spigot Diameter (A)	89 mm
Unit Type	ISKRA / LETRIKA
Voltage	12 V

Vehicle Applications

Make	Model	Type	Year
CASE	1394	[4-219D]	01.1983-01.1988
CASE	1494	[4-219D]	01.1983-01.1988
CASE	1494 2WD		01.1984-01.1987
CASE	1594 2WD		01.1984-01.1988
CASE	1690 2WD		01.1984-01.1985
CASE	1690 4WD		01.1984-01.1985
CASE	1694		01.1984-01.1987
CASE	2094		01.1984-12.1987
CASE	2294		01.1984-12.1987
CASE	2394		01.1984-12.1987
LANDINI	100 4.0	[1004-40T]
LANDINI	100 4.2	[1004-40T]
LANDINI	100 4.4	[1104D-44T]
LANDINI	100 F 4.4	[1104D-44TA]
LANDINI	100 GE 4.4	[1104D-44TA]
LANDINI	100 GT 4.0	[1004-40T]
LANDINI	100 GT 4.4	[1104D-44TA]
LANDINI	105 4.0	[1004]
LANDINI	105 4.4	[1104C-44T]
LANDINI	105 4.4	[1104D-44T]
LANDINI	105 F 4.4	[1104C-44]
LANDINI	105 GE 4.4	[1104C-44]
LANDINI	105 GT 4.4	[1104C-44]
LANDINI	70 4.0	[1004-40]
LANDINI	70 F 4.0	[1004-40]
LANDINI	70 GT 4.0	[1004-40]
LANDINI	70 L 4.0	[1004-40]
LANDINI	70 V 4.0	[1004-40]
LANDINI	75 4.4	[1104C-44]
LANDINI	75 F 4.4	[1104C-44]
LANDINI	75 GE 4.4	[1104C-44]
LANDINI	75 T 4.4	[1104C-44]
LANDINI	80 4.0	[1004-42]
LANDINI	80 4.4	[1104D-44]
LANDINI	80 F 4.2	[1004-42]
LANDINI	80 GT 4.2	[1004-42]
LANDINI	80 L 4.2	[1004-42]
LANDINI	80 V 4.2	[1004-42]
LANDINI	85 4.0	[1004]
LANDINI	85 4.4	[1104C-44]
LANDINI	85 F 4.4	[1104C-44]
LANDINI	85 GE 4.4	[1104C-44]
LANDINI	85 GT 4.4	[1104C-44]
LANDINI	90 4.0	[1004-40T]
LANDINI	90 G 4.0	[1004-40T]
LANDINI	90 GT 4.0	[1004-40T]
LANDINI	95 4.0	[1004]
LANDINI	95 4.4	[1104C-44]
LANDINI	95 4.4	[1104C-44T]
LANDINI	95 F 4.4	[1104C-44]
LANDINI	95 GE 4.4	[1104C-44]
LANDINI	95 GT 4.4	[1104C-44]
LANDINI	Frutteto RP50	[1004-42]
LANDINI	Frutteto RT40	[1004-42]
LANDINI	Globus 65 4.0	[1004-40]
LANDINI	Globus 75 4.0	[1004-42]
LANDINI	Globus 80 4.0	[1004-42]
LANDINI	Mythos 100 4.0	[1004-40T]
LANDINI	Mythos 90 4.0	[1004-40T]
LANDINI	Vigneto RP00	[1004-42]
LANDINI	Vigneto RT01	[1004-42]
MASSEY FERGUSON	MF 290
MCCORMICK	100 4.4	[1104A-44TA]
MCCORMICK	100 4.4	[1104D-44T]
MCCORMICK	100 4.4	[1104D-44TA]
MCCORMICK	105 4.4	[1104D-44T]
MCCORMICK	110 4.4	[1104D-44TA]
MCCORMICK	80 4.4	[1104D-44]
MCCORMICK	80 4.4	[1104D-44]
MCCORMICK	80 L 4.4	[1104D-44]
MCCORMICK	90 4.4	[1104D-44T]
MCCORMICK	90 4.4	[1104A-44]
MCCORMICK	90 4.4	[1104D-44T]
MCCORMICK	C70 L 3.3	[1103D-33TA]	01.2011-
MCCORMICK	CX 100 4.4	[1104D-44TA]
MCCORMICK	CX 110 4.4	[1104D-44TA]
MCCORMICK	CX 90 4.4	[1104D-44T]
MCCORMICK	F100 F 4.4	[1104D-44TA]
MCCORMICK	F100 GEL 4.4	[1104D-44TA]
MCCORMICK	F100 XL 4.4	[1104D-44TA]
MCCORMICK	F110 F 4.4	[1104D-44TA]
MCCORMICK	F110 GE 4.4	[1104D-44TA]
MCCORMICK	F110 XL 4.4	[1104D-44TA]
MCCORMICK	F70 F 3.3	[1103D-33TA]
MCCORMICK	F70 GE 3.3	[1103D-33TA]
MCCORMICK	F80 F 4.4	[1104D-44]
MCCORMICK	F80 GE 4.4	[1104D-44]
MCCORMICK	F80 N 4.4	[1104D-44]
MCCORMICK	F80 XL 4.4	[1104D-44]
MCCORMICK	F90 F 4.4	[1104D-44T]
MCCORMICK	F90 GE 4.4	[1104D-44T]
MCCORMICK	F90 N 4.4	[1104D-44T]
MCCORMICK	F90 XL 4.4	[1104D-44T]
MCCORMICK	MB 75 4.4	[1104A-44]
MCCORMICK	MB 85 4.4	[1104A-44]
MCCORMICK	MC 110 4.4	[1104D-TA]
MCCORMICK	MC 115 4.4	[1104D-44TA]
MCCORMICK	MC 130 4.4	[1104-44TA]
MCCORMICK	T100 4.4	[1104D-44T]
MCCORMICK	T105 4.4	[1104D-44T]
MCCORMICK	T80 4.4	[1104D-44T]
MCCORMICK	T90 4.4	[1104D-44T]
PERKINS	Engine 4.0	[1004-40]
PERKINS	Engine 4.0	[1004-42]

Reference Information

11.131.112	ISKRA / LETRIKA
11.131.315	ISKRA / LETRIKA
11.131.535	ISKRA / LETRIKA
11.131.975	ISKRA / LETRIKA
11.131.984	ISKRA / LETRIKA
11.131.990	ISKRA / LETRIKA
114107	CARGO
1447834M91	PERKINS
1482841M92	MASSEY FERGUSON
182-30102	ROBERT'S
191068M94	MASSEY FERGUSON
234987A1	CASE
254358	KUHNER
273-32103	DIXIE
3542185M93	MASSEY FERGUSON
3667037M91	MASSEY FERGUSON
3821818M91	MASSEY FERGUSON
4270745M2	SAME
4270745M2	MASSEY FERGUSON
4270745M2	AGCO
4TNV9876011	YANMAR
6021144	SANDO
700336A1	MASSEY FERGUSON
706022A1	LANDINI
760.002.103	PSH
760.002.103.460	PSH
8719R	CEVAM
9162904	MAGNETON
AZE4125	ISKRA / LETRIKA
AZE4212	ISKRA / LETRIKA
AZE4214	ISKRA / LETRIKA
AZE4216	ISKRA / LETRIKA
AZE4579	ISKRA / LETRIKA
CST21144	CASCO
CST21144AS	CASCO
CST21144ES	CASCO
CST21144GS	CASCO
CST21144OS	CASCO
CST21144RS	CASCO
F032114107	CARGO
IS1098	ISKRA / LETRIKA
MAHMS4	WOODAUTO
MAV231040	SIOM
MS4	MAHLE
MS 4	MAHLE
S9302S	AS-PL
SG9064	GHIBAUDI
STR79310	ELECTROLOG
STR79311	ELECTROLOG
STRS712	3EFFE
STX200678	STARDAX
STX210083	STARDAX
STX210084	STARDAX
TS-6276	DIXIE
UD13624S	AS-PL
