Associated Numbers
11.131.577 182-30360 504204112 AZE6528 IS1176 MAHMS288 MS288 UD809666(LETRIKA)SSpecifications
Kilowatt | 3 kW |
Length (L.1) | 242 mm |
Mount Hole Center - Center (O.1) | 70 mm |
Mount Hole Center - Center (O.2) | 122 mm |
Mount Hole Center - Center (O.3) | 95 mm |
Mount Hole Diameter (C.1) | M8x1.25 mm |
Mount Hole Diameter (C.2) | M8x1.25 mm |
Mount Hole Diameter (C.3) | M8x1.25 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 3 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 26.5 mm |
Rotation | CW |
Spigot Diameter (A) | 82 mm |
Unit Type | ISKRA / LETRIKA |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
IVECO | Engine |
Reference Information
STR79210 504204112 MAV236390 MS MAHMS288 6021639.1 20419936OE 182-30360 MS288 288 IS1176 CST21639GS 11.131.577 UD809666(LETRIKA)S AZE6528Video/Publications
11.131.577 182-30360 504204112 AZE6528 IS1176 MAHMS288 MS 288 UD809666(LETRIKA)SAdd Your Number
