Associated Numbers
0001359017 0001359062 0001367021 11.130.402 115535 254141 254141M 260-67128 530.001.092 6005706620 6010284 72735822 8952 AZJ3109 CST10284 CST10284AS CST10284ES CST10284GS CST10284OS CST10284RS IS0402 LETIS0402 MS194 STR22092 UD11896(LETRIKA)S UNIT BOM 120-6108 UNIT BOM 182-152Specifications
Kilowatt | 3 kW |
Length (L.1) | 338 mm |
Mount Hole Center - Center (O.1) | 105 mm |
Mount Hole Diameter (C.1) | 13 mm |
Mount Hole Diameter (C.2) | 13 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 21 mm |
Rotation | CW |
Spigot Diameter (A) | 82.5 mm |
Unit Type | ISKRA / LETRIKA |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
AGRIFULL | 80.105 5.7 | [1056SU] | 04.1981-12.1984 |
GOLDONI | Cingolato 360 | [SUN3105] | |
MUZZI | MD 60 5.7 | [1056] | 03.1980-12.1981 |
MUZZI | MD 60 6.0 | [SUN6105] | 01.1984-12.1988 |
MUZZI | MDS | [6105] | 01.1989- |
VM | 1056 M11 5.7 | 01.1973-12.1985 | |
VM | 1056 SU 5.7 | 01.1971-01.1986 | |
VM | 106 MH11 5.2 | 01.1973-12.1985 | |
VM | 106 SU 5.2 | 01.1973-12.1974 | |
VM | 50KVA | [1056SU] | 01.1971-01.1986 |
VM | 60KVA 5.7 | [1056SU] | 01.1971-01.1986 |
VM | 6105 6.0 | 01.1984- | |
VM | 6105 M 6.0 | 01.1986- | |
VM | 6150 T 6.0 | 01.1984- | |
VM | 70 KVA | [T1056SU] | 01.1976-01.1986 |
VM | T 1056SU |
Reference Information
72735822 35532032F 0001367021 8952 MS194 0001359062 1367021 IS0402 115535 STR22092 194 3.553.2032F 331036 1359017 CST10284OS 260-67128 0001359017 530.001.092 CST10284GS CST10284ES UD11896(LETRIKA)S 182-152 6005706620 CST10284AS 035530059A STR79010 BOM UNIT MS STR10059 254141 AZJ3109 254141M CST10284RS LETIS0402 120-6108 35530059A 6010284 1359062 11.130.402 CST10284Video/Publications
0001359017 0001359062 0001367021 11.130.402 115535 254141 254141M 260-67128 530.001.092 6005706620 6010284 72735822 8952 AZJ3109 CST10284 CST10284AS CST10284ES CST10284GS CST10284OS CST10284RS IS0402 LETIS0402 MS 194 MS194 STR22092 UD11896(LETRIKA)S UNIT BOM 120-6108 UNIT BOM 182-152Add Your Number
