Associated Numbers
0-23000-7292 023000-7292 20446016BN 20446016OE 244-74201 6050610 91-28-4025 CST50610 CST50610AS CST50610ES CST50610GS CST50610OS CST50610RS S-8858 S9188 UD11098S 16-347 dxs563 70-8529 snj816 snj038Specifications
| Kilowatt | 7.4 kW |
| Length (L.1) | 402 mm |
| Mount Hole Center - Center (O.1) | 175 mm |
| Mount Hole Diameter (C.1) | 14.5 mm |
| Mount Hole Diameter (C.2) | 14.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 11 qty |
| Pinion at Rest (B) | 56 mm |
| Rotation | CW |
| Spigot Diameter (A) | 105 mm |
| Unit Type | NIKKO |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| HITACHI | EX300 | 01.1991- | |
| HITACHI | EX300LC-3 SUPER | [6SD1T] | |
| HITACHI | EX330 | [65D1] | 01.1998- |
| ISUZU | Engine | [6SD1TP] | 01.1991- |
Reference Information
UD11098S 20446016BN CST50610AS S9188 CST50610ES S-8858 CST50610GS 91-28-4025 0-23000-7290 0-23000-7292 244-74201 1811002880 CST50610OS CST50610RS 6050610 CST50610 1811001941 20446016OE STR75236 1811002940 1811002941Video/Publications
0-23000-7292 023000-7292 20446016BN 20446016OE 244-74201 6050610 91-28-4025 CST50610 CST50610AS CST50610ES CST50610GS CST50610OS CST50610RS S-8858 S9188 UD11098SAdd Your Number
