Associated Numbers
254763 26201-7049 526-201-7124 65.26201-7059 M000A0301 M00A0301 M35017 TM000A0301 UD11082S UD11151SSpecifications
Kilowatt | 6 kW |
Length (L.1) | 386 mm |
Mount Hole Center - Center (O.1) | 127 mm |
Mount Hole Center - Center (O.2) | 90 mm |
Mount Hole Center - Center (O.3) | 90 mm |
Mount Hole Diameter (C.1) | 12 mm |
Mount Hole Diameter (C.2) | 12 mm |
Mount Hole Diameter (C.3) | 12 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
Pinion at Rest (B) | 48 mm |
Rotation | CW |
Spigot Diameter (A) | 89 mm |
Unit Type | NIKKO |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
DAEWOO | Engine | [DH220-3] | |
DOOSAN | Engine | [D1146] |
Reference Information
M00A0301 26201-7049 526-201-7124 254763 UD11151S 65.26201-7049 UD11082S M35017 TM000A0301 M000A0301Video/Publications
254763 26201-7049 526-201-7124 M000A0301 M00A0301 M35017 TM000A0301 UD11082S UD11151SAdd Your Number
