Associated Numbers
0-23000-1070 0-23000-1071 0-23000-1100 0-23000-2340 0-23000-2341 0-23000-2342 112649 18100N-ND 1811001910 1811001911 1811001912 1811002061 1811002530 1811002531 2-1951-NK 2-1951-NK-1 20446106BN 20446106OE 244-45200E 246-25232 246-25232E 6050601 91-28-4024 CST50601AS CST50601GS S-8565 S-8565E S-8565ER S-8565H S-8565HR STR6160 STR6176 UD11126S 16-346 dxs451 dxs550 70-8569 70-8569-1 snj050 snj050gqSpecifications
Kilowatt | 4.5 kW |
Length (L.1) | 296 mm |
Mount Hole Center - Center (O.1) | 111 mm |
Mount Hole Center - Center (O.2) | 111 mm |
Mount Hole Center - Center (O.3) | 135 mm |
Mount Hole Diameter (C.1) | 14 mm |
Mount Hole Diameter (C.2) | 14 mm |
Mount Hole Diameter (C.3) | 14 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
Pinion at Rest (B) | 38 mm |
Rotation | CW |
Spigot Diameter (A) | 105 mm |
Unit Type | NIKKO |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
ISUZU | Engine | [6BD1T] |
Reference Information
S-8565 S9167 2-1951-NK 5811001391 5811001390 112649 1811001891 91-28-4024 1811001890 1811002061 2-1951-NK-1 5811001620 MAV5740 0-23000-2342 0-23000-2340 0-23000-2341 S25103 CST50601GS 1811002591 6050601 714-36000 5811000360 0-23000-1100 1811001912 20446106OE S-8565HR S-8565H S-8565E 20446106BN 1811001910 1811001911 5811001560 246-25232 246-25232E 714/40236 1811002641 STR6160 18100N-ND CST50601AS 0-23000-1070 0-23000-1071 S-8565ER 1811002530 STR6176 1811004111 1811001921 1811001920 244-45200E 1811002531 UD11126SVideo/Publications
0-23000-1070 0-23000-1071 0-23000-1100 0-23000-2340 0-23000-2341 0-23000-2342 112649 18100N-ND 1811001910 1811001911 1811001912 1811002061 1811002530 1811002531 2-1951-NK 2-1951-NK-1 20446106BN 20446106OE 244-45200E 246-25232 246-25232E 6050601 91-28-4024 CST50601AS CST50601GS MAV5740 S-8565 S-8565E S-8565ER S-8565H S-8565HR STR6160 STR6176 UD11126S S9167Add Your Number
