Associated Numbers
0986014511 16835 20385 28100-72010 28100-72020 28100-72060 28100-72090 491Q 91-29-5065 S-8140Specifications
Kilowatt | 1.2 kW |
Length (L.1) | 209 mm |
Mount Hole Center - Center (O.1) | 113 mm |
Mount Hole Diameter (C.1) | M12x1.25 mm |
Mount Hole Diameter (C.2) | M12x1.25 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 9 qty |
No./Teeth (Replaces) | 9 qty |
Pinion at Rest (B) | 19 mm |
Rotation | CW |
Spigot Diameter (A) | 74 mm |
Unit Type | GREAT WALL |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
GREAT WALL | Brilliance 2.2 | [491Q] | |
GREAT WALL | Brilliance 2.7 | ||
GREAT WALL | Deer 2.2 | [491Q] | |
GREAT WALL | Jinbei 2.2 | [491Q] | |
GREAT WALL | Pegasus 2.2 CN | [491Q] | |
GREAT WALL | Safe 2.2 CN | [491Q] | |
GREAT WALL | Sing 2.2 CN | [491Q] | |
TOYOTA | Van 2.2 | 01.1986-12.1989 |
Reference Information
20385 E049161000001 442061 28100-72090 28100-72060 SD6RA123 28100-72020 STQ1715 MTT182 3708010 STR00201 S-8140 003-T182 MAV461040 986014511 91-29-5065 491Q 16835 3T182Video/Publications
003-T182 0986014511 16835 20385 28100-72010 28100-72020 28100-72060 28100-72090 3T182 491Q 91-29-5065 MAV461040 MTT182 S-8140Add Your Number
