Associated Numbers
12099 150.538.082 17763N 20493301 25-3204 254273V 254638 36100-37110 438100 455966 6032103 88213487 91-31-9004 944280705080 9788 AEY1658 CST32103 CST32103AS CST32103ES CST32103GS CST32103OS CST32103RS DRS3889 DS4999 J5210508 LRS01658 M62956 MRS70508 S-8776 STA3020 STR75007 TM000A14301 UD20433SSpecifications
Kilowatt | 1.2 kW |
Length (L.1) | 213 mm |
Mount Hole Center - Center (O.1) | 97 mm |
Mount Hole Diameter (C.1) | M10x1.25 mm |
Mount Hole Diameter (C.2) | M10x1.25 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 8 qty |
Pinion at Rest (B) | 17 mm |
Rotation | CW |
Spigot Diameter (A) | 70 mm |
Unit Type | MANDO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
HYUNDAI | Santa F 2.7 V6 4WD | [G6BA-G] | 02.2001- |
HYUNDAI | Sonata 2.5 V6 | [G6AV] | 08.1998-09.2001 |
HYUNDAI | Sonata 2.5 V6 24V | [G6BV-G] | 06.1998-10.2001 |
HYUNDAI | Trajet 2.7 V6 | [G6BA-G] | 09.2000- |
HYUNDAI | XG 3.0 V6 | [G6CT-G] | 12.1998-12.2005 |
KIA | Magentis 2.5 V6 | [G6BV] | 05.2001- |
Reference Information
CST32103 9788 M62956 254273V 12099 9.44281E+11 CST32103AS DS4999 MAV341030 AEY1658 MRS70508 220380 MTC123 150.538.082 DRS3889 CST32103RS 25-3204 455966 438100 CGB-27110 6032103 88213487 TM000A14301 STR8711 J5210508 003-C123 91-31-9004 S-8776 3C123 36100-37110 CST32103OS STR75007 STA3020 UD20433S 20493301 CST32103GS LRS1658 CST32103ES LRS01658 17763N 254638Video/Publications
003-C123 12099 150.538.082 17763N 20493301 25-3204 254273V 254638 36100-37110 3C123 438100 455966 6032103 88213487 91-31-9004 944280705080 9788 AEY1658 CGB-27110 CST32103 CST32103AS CST32103ES CST32103GS CST32103OS CST32103RS DRS3889 DS4999 J5210508 LRS01658 LRS1658 M62956 MAV341030 MRS70508 MTC123 S-8776 STA3020 STR75007 TM000A14301 UD20433S 220380Add Your Number
