Associated Numbers
031228070 OK87T-18-400 STY8070 UD02128SSpecifications
Kilowatt | 5.5 kW |
Length (L.1) | 314 mm |
Mount Hole Center - Center (O.1) | 140 mm |
Mount Hole Center - Center (O.2) | 119 mm |
Mount Hole Center - Center (O.3) | 106 mm |
Mount Hole Diameter (C.1) | 13.5 mm |
Mount Hole Diameter (C.2) | 13.5 mm |
Mount Hole Diameter (C.3) | 13.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
No./Teeth (Replaces) | 11 qty |
Pinion at Rest (B) | 28 mm |
Rotation | CW |
Spigot Diameter (A) | 100 mm |
Unit Type | POONGSUNG |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
HINO | Engine | [EH70] | |
HYUNDAI | Country Bus | ||
KIA | 5 Ton | ||
KIA | Rhino | ||
KIA | Rhino 55 |
Reference Information
31228070 STY8070 UD02128S OK87T-18-400Video/Publications
031228070 OK87T-18-400 STY8070 UD02128SAdd Your Number
