Associated Numbers
0001110076 0001110077 0001110098 0001110099 0001124003 0001124004 0001125005 0001125006 0001125014 0001125035 0001125036 0041518701 020911023B 020911023D 020911023DX 020911023P 020911023PX 020911023R 020911024A 068911023T 068911023TX 101287 1032666 10713 10789 11.130.723 11.131.057 112286 1M2111000AA 20500966 300.523.093 35259250 443115141395 8213123 9141395 9141396 915109E 95VW11000EB 95VW11000EC 97VW11000BA 97VW11000BB A0041518701 AZE2537 AZE2626 D7RS129 D7RS29 EAA-121627 M1209H M1210E M1210G S9083 STB0713Specifications
Kilowatt | 1.7 kW |
Length (L.1) | 168 mm |
Mount Hole Center - Center (O.1) | 33 mm |
Mount Hole Center - Center (O.2) | 111 mm |
Mount Hole Center - Center (O.3) | 123 mm |
Mount Hole Diameter (C.1) | 12.5 mm |
Mount Hole Diameter (C.2) | 12.5 mm |
Mount Hole Diameter (C.3) | 12.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
No./Teeth (Replaces) | 9 qty |
Pinion at Rest (B) | 33 mm |
Rotation | ACW |
Spigot Diameter (A) | 76 mm |
Unit Type | MAGNETON |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
AUDI | A3 1.9 TDi | [AGR] | 09.1996-07.2001 |
AUDI | A3 1.9 TDi | [AHF] | 01.1997-08.2000 |
AUDI | A3 1.9 TDi | [ALH] | 09.1996-07.2001 |
AUDI | A3 1.9 TDi | [ASV] | 09.1999-07.2001 |
FORD | Galaxy 1.9 TDi | [AVG] | 08.1997-04.2000 |
FORD | Galaxy 2.0 i | [NSE] | 11.1995- |
FORD | Galaxy 2.3 16V | [Y5B] | 01.1997- |
FORD | Galaxy 2.8 i | [AAA] | 02.1995-04.1998 |
FORD | Galaxy 2.8 i 4x4 | [AAA] | 04.1996-04.1998 |
FORD | Taurus 3.8 GL | 01.1988-01.1990 | |
MERCEDES BENZ | V 280 2.8 | (638)[M104.900] | 08.1997-07.2003 |
SEAT | Alhambra 1.9 TDi | [AFN] | 08.1996-06.2000 |
SEAT | Alhambra 1.9 TDi | [AVG] | 08.1996-06.2000 |
SEAT | Cordoba 1.9 D | [1Y] | 01.1996-08.1996 |
SEAT | Cordoba 1.9 D | [1Y] | 02.1993-08.1996 |
SEAT | Cordoba 1.9 SDi | [AEF] | 08.1996-06.1999 |
SEAT | Cordoba 1.9 SDi | [AEY] | 08.1996-06.1999 |
SEAT | Cordoba 1.9 SDi | [AEY] | 09.1996-06.1999 |
SEAT | Cordoba 1.9 SDi | [AGP] | 06.1999- |
SEAT | Cordoba 1.9 SDi | [AGP] | 06.1999-10.2002 |
SEAT | Cordoba 1.9 SDi | [AQM] | 06.1999- |
SEAT | Cordoba 1.9 SDi | [AQM] | 06.1999-10.2002 |
SEAT | Cordoba 1.9 TD | [AAZ] | 02.1993-08.1996 |
SEAT | Ibiza 1.9 D | [1Y] | 04.1993-08.1996 |
SEAT | Ibiza 1.9 D | [1Y] | 10.1994-08.1996 |
SEAT | Ibiza 1.9 SDi | [AEF] | 08.1996-08.1999 |
SEAT | Ibiza 1.9 SDi | [AEY] | 08.1996-08.1999 |
SEAT | Ibiza 1.9 SDi | [AGP] | 08.1999-02.2002 |
SEAT | Ibiza 1.9 SDi | [AQM] | 08.1999-02.2002 |
SEAT | Ibiza 1.9 TD | [AAZ] | 03.1993-08.1996 |
SEAT | Inca 1.7 D | [AHB] | 09.1996- |
SEAT | Inca 1.9 D | [1Y] | 11.1995- |
SEAT | Inca 1.9 SDi | [AEY] | 11.1995- |
SEAT | Inca 1.9 SDi | [AYQ] | 09.2000- |
SEAT | Leon 1.9 SDi | [AQM] | 11.1999- |
SEAT | Leon 1.9 TDi | [ALH] | 11.1999- |
SEAT | Toledo 1.9 D | [1Y] | 05.1991-03.1999 |
SEAT | Toledo 1.9 D | [1Y] | 12.1995-03.1999 |
SEAT | Toledo 1.9 SDi | [AQM] | 11.1999-06.2004 |
SEAT | Toledo 1.9 TD | [AAZ] | 05.1991-03.1999 |
SEAT | Toledo 1.9 TDi | [AGR] | 04.1999-05.2006 |
SEAT | Toledo 1.9 TDi | [AHF] | 04.1999-05.2006 |
SEAT | Toledo 1.9 TDi | [ALH] | 04.1999-05.2006 |
SEAT | Toledo 2.3 V5 | [AGZ] | 04.1999-05.2001 |
SEAT | Toledo 2.3 V5 | [AQN] | 05.2001-05.2006 |
SKODA | Octavia 1.9 SDi | [AGP] | 06.1997- |
SKODA | Octavia 1.9 SDi | [AGP] | 07.1998-12.2003 |
SKODA | Octavia 1.9 SDi | [AQM] | 06.1997- |
SKODA | Octavia 1.9 SDi | [AQM] | 07.1998-12.2003 |
SKODA | Octavia 1.9 TDi | [AGR] | 07.1998- |
SKODA | Octavia 1.9 TDi | [AGR] | 09.1996- |
SKODA | Octavia 1.9 TDi | [AHF] | 07.1998- |
SKODA | Octavia 1.9 TDi | [AHF] | 08.1997-09.2004 |
SKODA | Octavia 1.9 TDi | [ALH] | 07.1998- |
SKODA | Octavia 1.9 TDi | [ALH] | 09.1996- |
SKODA | Octavia 1.9 TDi | [ASV] | 07.1998- |
SKODA | Octavia 1.9 TDi | [ASV] | 08.2000-09.2004 |
SKODA | Octavia 1.9 TDi 4x4 | [AGR] | 11.1999-09.2000 |
VW | Bora 1.9 SDi | [AGP] | 10.1998-05.2005 |
VW | Bora 1.9 SDi | [AQM] | 10.1998-05.2005 |
VW | Bora 1.9 TDi | [AGR] | 10.1998-06.2001 |
VW | Bora 1.9 TDi | [AHF] | 05.1999-06.2001 |
VW | Bora 1.9 TDi | [AHF] | 10.1998-06.2001 |
VW | Bora 1.9 TDi | [ALH] | 10.1998-06.2001 |
VW | Bora 1.9 TDi | [ASV] | 05.1999-06.2001 |
VW | Bora 1.9 TDi 4-Motion | [AGR] | 02.1999-06.2001 |
VW | Bora 1.9 TDi 4-Motion | [ALH] | 02.1999-06.2001 |
VW | Bora 2.3 V5 | [AGZ] | 05.1999-10.2000 |
VW | Bora 2.3 V5 | [AGZ] | 10.1998-10.2000 |
VW | Bora 2.3 V5 4-Motion | [AGZ] | 05.1999-10.2000 |
VW | Bora 2.3 V5 4-Motion | [AGZ] | 12.1998-10.2000 |
VW | Caddy 1.7 SDi | [AHB] | 07.1996-09.2000 |
VW | Caddy 1.9 D | [1Y] | 11.1995- |
VW | Caddy 1.9 D | [1Y] | 11.1995-01.2004 |
VW | Caddy 1.9 SDi | [AEY] | 11.1995-01.2004 |
VW | Caddy 1.9 SDi | [AYQ] | 11.1995-01.2004 |
VW | Corrado 2.9 VR6 | [ABV] | 08.1991-12.1995 |
VW | Golf III 1.9 D | [1Y] | 07.1993-04.1999 |
VW | Golf III 1.9 D | [1Y] | 11.1991-08.1997 |
VW | Golf III 1.9 SDi | [AEY] | 07.1995-04.1999 |
VW | Golf III 1.9 SDi | [AEY] | 07.1995-08.1997 |
VW | Golf III 1.9 TD | [AAZ] | 07.1993-04.1999 |
VW | Golf III 1.9 TD | [AAZ] | 11.1991-08.1997 |
VW | Golf III 1.9 TDi | [1Z] | 03.1994-04.1999 |
VW | Golf III 1.9 TDi | [1Z] | 08.1995-05.1998 |
VW | Golf III 1.9 TDi | [1Z] | 09.1993-08.1997 |
VW | Golf III 1.9 TDi | [AFN] | 04.1996-04.1999 |
VW | Golf III 1.9 TDi | [AFN] | 04.1996-08.1997 |
VW | Golf III 1.9 TDi | [AFN] | 07.1996-05.1998 |
VW | Golf III 1.9 TDi | [AHU] | 03.1994-04.1999 |
VW | Golf III 1.9 TDi | [AHU] | 08.1995-05.1998 |
VW | Golf III 1.9 TDi | [AHU] | 09.1993-08.1997 |
VW | Golf III 1.9 TDi | [ALE] | 05.1997-12.1997 |
VW | Golf III 1.9 TDi | [ALE] | 08.1995-05.1998 |
VW | Golf III 2.8 VR6 | [AAA] | 01.1992-08.1997 |
VW | Golf IV 1.6 | [AWB] | 08.2003-06.2005 |
VW | Golf IV 1.9 SDi | [AGP] | 05.1999- |
VW | Golf IV 1.9 SDi | [AGP] | 08.1997-06.2005 |
VW | Golf IV 1.9 SDi | [AQM] | 05.1999- |
VW | Golf IV 1.9 SDi | [AQM] | 08.1997-06.2005 |
VW | Golf IV 1.9 TDi | [AGR] | 10.1997-05.2004 |
VW | Golf IV 1.9 TDi | [AHF] | 05.1999-06.2001 |
VW | Golf IV 1.9 TDi | [AHF] | 08.1997-05.2004 |
VW | Golf IV 1.9 TDi | [AHU] | 04.1998-06.2000 |
VW | Golf IV 1.9 TDi | [ALE] | 04.1998-12.2001 |
VW | Golf IV 1.9 TDi | [ALH] | 05.1999-05.2005 |
VW | Golf IV 1.9 TDi | [ALH] | 05.1999-05.2006 |
VW | Golf IV 1.9 TDi | [ALH] | 10.1997-05.2004 |
VW | Golf IV 1.9 TDi | [ASV] | 08.1997-05.2004 |
VW | Golf IV 1.9 TDi 4-Motion | [AGR] | 05.1999-05.2005 |
VW | Golf IV 1.9 TDi 4-Motion | [AGR] | 07.1998-04.2002 |
VW | Golf IV 1.9 TDi 4-Motion | [ALH] | 07.1998- |
VW | Golf IV 2.3 V5 | [AGZ] | 05.1999- |
VW | Golf IV 2.3 V5 | [AGZ] | 08.1997-10.2000 |
VW | Golf IV 2.3 V5 4-Motion | [AGZ] | 05.1999- |
VW | Golf IV 2.3 V5 4-Motion | [AGZ] | 12.1998-10.2000 |
VW | New Beetle 1.9 TDi | [ALH] | 01.1998-06.2004 |
VW | Passat 1.9 D | [1Y] | 05.1989-10.1993 |
VW | Passat 1.9 TD | [AAZ] | 03.1991-05.1997 |
VW | Passat 1.9 TD | [AAZ] | 03.1991-08.1996 |
VW | Passat 1.9 TDi | [1Z] | 10.1993-05.1997 |
VW | Passat 1.9 TDi | [1Z] | 10.1993-08.1996 |
VW | Passat 1.9 TDi | [AFN] | 03.1996-03.1997 |
VW | Passat 1.9 TDi | [AFN] | 03.1996-05.1997 |
VW | Passat 2.8 VR6 | [AAA] | 06.1991-05.1997 |
VW | Passat 2.8 VR6 | [AAA] | 06.1991-08.1996 |
VW | Passat 2.8 VR6 GLX | [AAA] | 01.1995-01.1995 |
VW | Polo 1.7 SDi | [AKW] | 07.1997-09.2001 |
VW | Polo 1.7 SDi | [AKW] | 08.1997-09.2001 |
VW | Polo 1.9 D | [1Y] | 01.1996-10.1996 |
VW | Polo 1.9 D | 06.1996-09.2001 | |
VW | Polo 1.9 SDi | [1Y] | 12.1995-08.1999 |
VW | Polo 1.9 SDi | [AEY] | 06.1997-09.2001 |
VW | Polo 1.9 SDi | [AEY] | 12.1995-08.1999 |
VW | Polo 1.9 SDi | [AGP] | 08.1999-09.2001 |
VW | Polo 1.9 SDi | [AQM] | 08.1999-09.2001 |
VW | Sharan 1.9 TDi | [AFN] | 09.1996-04.2000 |
VW | Sharan 2.8 VR6 | [AAA] | 09.1995-04.2000 |
VW | Sharan 2.8 VR6 | [AMY] | 09.1995-04.2000 |
VW | Sharan 2.8 VR6 Syncro | [AAA] | 11.1996-04.2000 |
VW | Sharan 2.8 VR6 Syncro | [AMY] | 11.1996-04.2000 |
VW | Transporter 2.5 TD | [AJT] | 05.1998-04.2003 |
VW | Transporter 2.5 TDi | [ACV] | 09.1995-03.2004 |
VW | Transporter 2.5 TDi | [ACV] | 09.1995-04.2003 |
VW | Transporter 2.5 TDi | [AJT] | 05.1998-03.2004 |
VW | Transporter 2.5 TDi | [AJT] | 12.1998-04.2003 |
VW | Transporter 2.5 TDi | [AUF] | 09.1995-03.2004 |
VW | Transporter 2.5 TDi | [AUF] | 09.1995-04.2003 |
VW | Transporter 2.5 TDi Syncro | [ACV] | 01.1996-03.2004 |
VW | Transporter 2.5 TDi Syncro | [ACV] | 05.1998-04.2003 |
VW | Transporter 2.5 TDi Syncro | [ACV] | 09.1995-04.2003 |
VW | Transporter 2.5 TDi Syncro | [AXL] | 05.1998- |
VW | Transporter 2.8 | [AES] | 05.1996-05.2000 |
VW | Vento 1.9 D | [1Y] | 11.1991-09.1998 |
VW | Vento 1.9 SDi | [AEY] | 04.1997-09.1998 |
VW | Vento 1.9 TD | [AAZ] | 11.1991-09.1998 |
VW | Vento 1.9 TDi | [1Z] | 09.1993-09.1998 |
VW | Vento 1.9 TDi | [AFN] | 04.1996-09.1998 |
VW | Vento 1.9 TDi | [AHU] | 09.1993-09.1998 |
VW | Vento 1.9 TDi | [ALE] | 09.1993-09.1998 |
VW | Vento 2.8 VR6 | [AAA] | 01.1992-09.1998 |
Reference Information
4.43115E+11 020911024AX 48 1110077 1110076 STRS055 S9083 0001110076 0001110077 D7RS29 9141395 9141396 020911012P 1124004 41518701 1124003 300.523.093 1032666 1125014 0001125005 0001125006 11.131.057 MAV6450 S12BH0142A2 95VW11000EA 020911023DX MS 101287 220388 A0041518701 10789 97VW11000BA 97VW11000BB 020911023PX MAV172100 20500966 M1210G EAA-121627 1147435 098911023B M1210E 098911023A 0001124004 112286 11.130.723 0001125014 0001124003 95VW11000EC VVW020911024C 95VW11000EB 0001125035 1110099 1110098 1125035 35259250 068911023T 915109E 0001110098 068911023TX 0001110099 10713 1125036 020911023B AZE2626 020911023D M1209H STB0713 95VW11000GC MAV3020 D7RS129 MAV172090 020911023R 1HS911023D 1M2111000AA 8213123 020911023P STRS741 220131 303 020911024C 1125005 0001125036 1125006 AZE2537 STRX717 020911024A CS713Video/Publications
0001110076 0001110077 0001110098 0001110099 0001124003 0001124004 0001125005 0001125006 0001125014 0001125035 0001125036 0041518701 020911023B 020911023D 020911023DX 020911023P 020911023PX 020911023R 020911024A 068911023T 068911023TX 101287 1032666 10713 10789 11.130.723 11.131.057 112286 1M2111000AA 20500966 300.523.093 35259250 443115141395 8213123 9141395 9141396 915109E 95VW11000EB 95VW11000EC 97VW11000BA 97VW11000BB A0041518701 AZE2537 AZE2626 CS713 D7RS129 D7RS29 EAA-121627 M1209H M1210E M1210G MAV172090 MAV172100 MAV3020 MAV6450 MS 303 MS 48 S9083 STB0713 STRS055 STRS741 220131 220388Add Your Number
