Associated Numbers
0-24000-0088 0-24000-0148 0-24000-0168 0-24000-0178 0240000178 114659 131.516.133 185-24022 19763N 45-4429 4HK1 6050621 8980700630 8980703211 CST50621 CST50621AS CST50621ES CST50621GS CST50621OS CST50621RS LRS02756 S9068 STK4278 STR75224 UD16467S 16478 NXS9723Specifications
Kilowatt | 5 kW |
Length (L.1) | 306 mm |
Mount Hole Center - Center (O.1) | 113 mm |
Mount Hole Center - Center (O.2) | 60.5 mm |
Mount Hole Center - Center (O.3) | 87 mm |
Mount Hole Diameter (C.1) | 13 mm |
Mount Hole Diameter (C.2) | M10x1.25 mm |
Mount Hole Diameter (C.3) | 13 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 1 qty |
No./Teeth | 13 qty |
No./Teeth (Replaces) | 13 qty |
Pinion at Rest (B) | 13 mm |
Rotation | CW |
Spigot Diameter (A) | 90 mm |
Unit Type | NIKKO |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
ISUZU | Engine | [4HK1] |
Reference Information
8980703211 S9068 8980703210 E02GES094 87597118 02-24-3024 4HK1 0-24000-0178 LRS2756 89807321 88214243 0-61000-0260 6050621.1 PRSS289 20446126OE STR7915 87560107 254564N 20446126BN 45-4429 254564 71440472 19763N S24NK0030A2 0-24000-0148 STK4278 8980019150 131.516.133.148 5150162 LRS02756 0-24000-0088 0-24000-0168 8980540630 131.516.133.140 CST50621AS 185-24022 UD16467S CST50621GS 114659 STR8837 STRS289 6050621 CGB-23127 131.516.133.710 71440521 87711539 STR75224Video/Publications
0-24000-0088 0-24000-0148 0-24000-0168 0-24000-0178 0240000178 114659 131.516.133 185-24022 19763N 45-4429 4HK1 6050621 8980700630 8980703211 CST50621 CST50621AS CST50621ES CST50621GS CST50621OS CST50621RS LRS02756 LRS2756 S9068 STK4278 STR75224 STRS289 UD16467S 87560107 87597118 87711539Add Your Number
