Associated Numbers
0001364001 19024805 45-1374 LRS01864 R10.01 R10A S9066 STD4805Specifications
Kilowatt | 4.8 kW |
Length (L.1) | 353 mm |
Mount Hole Center - Center (O.1) | 127 mm |
Mount Hole Center - Center (O.2) | 127 mm |
Mount Hole Center - Center (O.3) | 127 mm |
Mount Hole Diameter (C.1) | 10.5 mm |
Mount Hole Diameter (C.2) | 10.5 mm |
Mount Hole Diameter (C.3) | 10.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
No./Teeth (Replaces) | 11 qty |
Pinion at Rest (B) | 45 mm |
Rotation | CW |
Spigot Diameter (A) | 92 mm |
Unit Type | OTHER |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
BIZON | 5056 Combine | [SW-400] | |
BIZON | 5058 Combine | [SW-400] | |
BIZON | Various Models | [SW-400] | |
BIZON | Z040 | [SW-400] | |
BIZON | Z042 | [SW-400] | |
BIZON | Z050 | [SW-400] | |
STAR | 742 | [4CT107] | |
STAR | 742 | [6CT107] | |
STAR | 742 | [SW-400] |
Reference Information
STRF742 CST10746ES 6010746.3 S9066 R10.01 19024805 45-1374 20401647EL MAV127460EL R10A 1364001 LRS1864 0001364001 LRS01864 STD4805Video/Publications
0001364001 19024805 45-1374 LRS01864 LRS1864 R10.01 R10A S9066 STD4805 STRF742Add Your Number
