Associated Numbers
26.0002M R10CSpecifications
| Kilowatt | 4.8 kW |
| Length (L.1) | 352 mm |
| Mount Hole Center - Center (O.1) | 90 mm |
| Mount Hole Center - Center (O.2) | 127 mm |
| Mount Hole Center - Center (O.3) | 90 mm |
| Mount Hole Diameter (C.1) | 11 mm |
| Mount Hole Diameter (C.2) | 11 mm |
| Mount Hole Diameter (C.3) | 11 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 11 qty |
| Pinion at Rest (B) | 46 mm |
| Rotation | CW |
| Spigot Diameter (A) | 89 mm |
| Unit Type | OTHER |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| STAR | 1142 | [S-359] | 01.1986-12.2000 |
| STAR | 200 | [S-359] | 01.1976-12.1994 |
| STAR | 244 | [S-359] | 01.1975-12.2000 |
| STAR | 266 | [S-359] | 01.1973-12.2000 |
Reference Information
26.0002M R10CVideo/Publications
26.0002M R10CAdd Your Number
