Associated Numbers
64.942.801 80350911 9142742Specifications
Kilowatt | 2.7 kW |
Length (L.1) | 236 mm |
Mount Hole Center - Center (O.1) | 127 mm |
Mount Hole Center - Center (O.2) | 90 mm |
Mount Hole Center - Center (O.3) | 90 mm |
Mount Hole Diameter (C.1) | 11 mm |
Mount Hole Diameter (C.2) | 11 mm |
Mount Hole Diameter (C.3) | 11 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
No./Teeth (Replaces) | 11 qty |
Pinion at Rest (B) | 47.5 mm |
Rotation | CW |
Spigot Diameter (A) | 89 mm |
Unit Type | MAGNETON |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
URSUS | 1012 4.5 | [Z 8002.1Turbo] | |
URSUS | 1012 4.5 | [Z8002.1Turbo] | |
URSUS | 1014 4.5 | [Z 8002.1Turbo] | |
URSUS | 1014 4.5 | [Z8002.1Turbo] | |
URSUS | 1033 4.5 | [Z 8002.13] | |
URSUS | 1033 4.5 | [Z8002.13] | |
URSUS | 1035 4.5 | [Z 8002.13] | |
URSUS | 1035 4.5 | [Z8002.13] | |
URSUS | 1133 4.5 | [Z 8002.12] | |
URSUS | 1133 4.5 | [Z8002.12] | |
URSUS | 1135 4.5 | [Z8002.12] | |
URSUS | 912 4.5 | [Z 8401.1] | |
URSUS | 912 4.5 | [Z8401.1] | |
URSUS | 914 4.5 | [Z 8401.1] | |
URSUS | 914 4.5 | [Z8401.1] | |
URSUS | 933 4.5 | [Z 8401.12] | |
URSUS | 933 4.5 | [Z8401.12] | |
URSUS | 935 | [Z 8401.12] | |
URSUS | 935 | [Z8401.12] | |
URSUS | C 385 | ||
ZETOR | 10011 | [8002] | 01.1975-01.1980 |
ZETOR | 10045 | [8002] | 01.1975-01.1980 |
ZETOR | 12011 | [8601] | 01.1969-01.1980 |
ZETOR | 8011 | [8001] | |
ZETOR | 8045 | [8001] | 01.1969-01.1980 |
Reference Information
64.942.801 S9049 80350911 123708009 9142742Video/Publications
123708009 64.942.801 80350911 9142742Add Your Number
