Associated Numbers
0986022131 101341 101341V 113908 12008 1229427 1233234 1254222 1368970 1469712 20450901OE 22.1341 25-3390 3123 32508N 3M5T11000CB 3M5T11000CC 3M5T11000CD 3M5T11000CE 3M5T11000CF 6014109 8080216 8213302 8603690 88213302 8EA011610-271 8EA011610-331 8EA738258-001 8EA738258-091 AEY2219 CS1341 CST14109AS CST14109GS DRS3968 DRS3968N EAA-121099 GP-S9036-A LRS02219 S9036 SS465 STR61812 Y601-18-400A Y601-18-400B Y601-18-400CSpecifications
Kilowatt | 1.2 kW |
Length (L.1) | 217 mm |
Mount Hole Center - Center (O.1) | 116 mm |
Mount Hole Center - Center (O.2) | 74 mm |
Mount Hole Center - Center (O.3) | 83.5 mm |
Mount Hole Diameter (C.1) | 9.5 mm |
Mount Hole Diameter (C.2) | M10x1.5 mm |
Mount Hole Diameter (C.3) | M8x1.25 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 11 qty |
No./Teeth (Replaces) | 11 qty |
Pinion at Rest (B) | 13 mm |
Rotation | CW |
Unit Type | FORD |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
FORD | C-Max 1.6 TDCi | 02.2007- | |
FORD | Focus 1.6 TDCi | [G8DA] | 11.2004- |
FORD | Focus 1.6 TDCi | [G8DB] | 11.2004- |
FORD | Focus 1.6 TDCi | [HHDA] | 05.2005- |
FORD | Focus 1.6 TDCi C-Max | [G8DA] | 10.2003-03.2007 |
FORD | Focus 1.6 TDCi C-Max | [G8DB] | 10.2003-03.2007 |
FORD | Focus 1.6 TDCi C-Max | [HHDA] | 06.2005-03.2007 |
FORD | Focus 1.6 TDCi C-Max | [HHDB] | 06.2005-03.2007 |
MAZDA | 3 1.6 TD | [Y601] | 06.2004- |
MAZDA | 3 1.6 Turbo Di | [Y601] | 06.2004- |
VOLVO | C30 1.6 Diesel | [D4164T] | 10.2006- |
VOLVO | S40 1.6 Diesel | [D4164T] | 01.2005- |
VOLVO | V50 1.6 Diesel | [D4164T] | 01.2005- |
Reference Information
3M5T-11000-CC 3M5T-11000-CB 3M5T-11000-CE 3M5T-11000-CD 3M5T-11000-CG 3M5T-11000-CF 3123 446522 BG9T-11000-AA 590.539.113.020 DRS3968 1254222 F042S0H069 MAV161090A MAV161090 2S0124 101341VA S9036 20450901BN 0001986S01017 590.539.113.028 BG9T11000AA 32508N SG0388 25-3390 6014109 6014109.1 9.43213E+11 STF1341 S12VS0193A2 63280029 1469712 20-100-01029 30644972 986022131 DRS3968N CST14109GS RE3M5T-11000-CF 8EA011610-271 113908 S12VS0193 1229427 RE3M5T11000CF CS1341 220371 STM1060 36013613 1233234 30795406 AI-80035 116062 BS51-11000-AA 220371A LRS2219 1707507 EAA-121099 GS001029-A 1762872 LRS002219 30667060 8EA738258-091 8603690 1986S01017 BS5111000AA 88213302 30667739 101341V 2S0124X 000986022131 2073366 42022131 20450901OE AEY2219 GS001029VI-R RM3M5T-11000-CF Y601-18-400C Y601-18-400A Y601-18-400B 2109635 1368970 STR61812 590.539.113.235 FL1WA 5014010 590.539.113.231 458650 LRS02219 MSN8029 MSRC1341 CST14109AS 101341 63280029010 STA0290R STR8914 36003219 1715776 RM3M5T11000CFVideo/Publications
0986022131 101341 101341V 113908 12008 1229427 1233234 1254222 1368970 1469712 20450901OE 22.1341 25-3390 30644972 3123 32508N 3M5T11000CB 3M5T11000CC 3M5T11000CD 3M5T11000CE 3M5T11000CF 6014109 8080216 8213302 8603690 88213302 8EA011610-271 8EA011610-331 8EA738258-001 8EA738258-091 AEY2219 CS1341 CST14109AS CST14109GS DRS3968 DRS3968N EAA-121099 GP-S9036-A LRS02219 LRS2219 MAV161090 RNL3M5TCE SS465 STR61812 STRW407 SX 5073 Y601-18-400A Y601-18-400B Y601-18-400C 220371Add Your Number
