Associated Numbers
228000-5490 UD16983S CST40238AS CST40238GS 9724 DRS3638 228000-5670 228000-5680 S-8455 25-3156 J5212100 STN3244 STN5244 LRS01628 944280721000 MRS72100 88212556 190.544.132 20432832BN 20432832OE STM680 6040238.0 6040238.1 28100-03090 28100-74230 28100-74240 17715N 17715R 91-29-5475 91-29-5475N STR8064Specifications
| Kilowatt | 1.4 kW |
| Length (L.1) | 217 mm |
| Mount Hole Center - Center (O.1) | 122 mm |
| Mount Hole Diameter (C.1) | 12.5 mm |
| Mount Hole Diameter (C.2) | 12.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 13 qty |
| Pinion at Rest (B) | 66 mm |
| Rotation | ACW |
| Spigot Diameter (A) | 55 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| TOYOTA | Camry 3.0 24V | 08.1996-11.2001 | |
| TOYOTA | Corolla 1.6 VVT-i | 01.2002-12.2006 |
Reference Information
DS4748 9.44281E+11 17715N STM680 STN5244 STR6459 91-29-5475N 28100-74240 UD16983S 228000-5490 28100-74230 MRS72100 25-3156 DRS3638 STN3244 228000-5680 228000-5670 220483 LRS1628 LRS01628 91-29-5475 28100-03090 STR8064Video/Publications
17715N 228000-5490 228000-5670 228000-5680 25-3156 28100-03090 28100-74230 28100-74240 91-29-5475 91-29-5475N 944280721000 DRS3638 DS4748 LRS01628 LRS1628 MRS72100 STM680 STN3244 STN5244 STR8064 UD16983S 220483Add Your Number
